7705 SAR

R5.0 Configuration Note

SAR

Introduction

The 8-port Voice & Teleprotection (VT) Card was introduced in release 5.0.R4 to provide the 7705 SAR platform with enhanced capabilities for replacing aging equipment within the Strategic Industries (SI) market, including utility, transport, government and defense applications. The VT card supports two FXO and two FXS (Foreign eXchange Office / Foreign eXchange Subscriber) ports for analog voice (Release 5.0.R7), two G.703 co-directional ports (Release 5.0.R4), and two C37.94 optical teleprotection ports (Release 5.0.R5).

The goal of this configuration note is to provide the steps required to configure and verify ITU-T G.703 co-directional on the 7705 SAR platform.

Setup

Figure 1 - Network setup

Prerequisites:

- MDAs and network ports are configured.

- IGP/static routing/MPLS or GRE are configured.

- SDPs are configured (The transport protocol used for this setup is LDP).

Configuration

Configure the Voice and Teleprotection MDAs on both SAR8-128 and SAR8-130.

A:SAR8-128# configure card 1 mda 6 mda-type a8-vt

A:SAR8-130# configure card 1 mda 3 mda-type a8-vt

Verify the MDAs are operational:

A:SAR8-128# show mda

===============================================================================

MDA Summary

===============================================================================

Slot Mda Provisioned Equipped Admin Operational

Mda-type Mda-type State State

-------------------------------------------------------------------------------

1 1 a8-ethv2 a8-ethv2 up up

6 a8-vt a8-vt up up

===============================================================================

A:SAR8-130# show mda

===============================================================================

MDA Summary

===============================================================================

Slot Mda Provisioned Equipped Admin Operational

Mda-type Mda-type State State

-------------------------------------------------------------------------------

1 1 a8-eth a8-eth up up

2 a8-ethv2 a8-ethv2 up up

3 a8-vt a8-vt up up

4 a16-chds1 a16-chds1 up up

===============================================================================

Configure port 1/6/3 on SAR8-128 and port 1/3/3 on SAR8-130 for G.703 codir operation and define channel group settings:

configure

port <port-id>

tdm

codir

channel-group 1

encap-type cem

no shutdown

exit

no shutdown

exit

no shutdown

Note: G.703 ports always use channel group 1 and have no timeslot.

Configure the Cpipe service on both 7705 SARs.

SAR8-128 configuration:

A:SAR8-128# configure service cpipe 13 customer 1 vc-type cesopsn create

A:SAR8-128>config>service>cpipe# info

----------------------------------------------

description "G.703 VT Card Example"

sap 1/6/3.1 create

exit

spoke-sdp 130:13 create

exit

no shutdown

----------------------------------------------

SAR8-130 configuration:

A:SAR8-130# configure service cpipe 13 customer 1 vc-type cesopsn create

A:SAR8-130>config>service>cpipe# info

----------------------------------------------

description "G.703 VT Card Example"

sap 1/3/3.1 create

exit

spoke-sdp 128:13 create

exit

no shutdown

----------------------------------------------

Verification and troubleshooting

1. Verify the Cpipe service operation on both 7705 SARs:

*A:SAR8-128# show service id 13 all

===============================================================================

Service Detailed Information

===============================================================================

Service Id : 13

Service Type : Cpipe VLL Type : CESoPSN

Description : G.703 VT Card Example

Customer Id : 1

Last Status Change: 07/06/2012 15:48:36

Last Mgmt Change : 07/06/2012 14:34:27

Admin State : Up Oper State : Up

MTU : 1514

Vc Switching : False

SAP Count : 1 SDP Bind Count : 1

-------------------------------------------------------------------------------

Service Destination Points(SDPs)

-------------------------------------------------------------------------------

Sdp Id 130:13 -(10.10.10.130)

-------------------------------------------------------------------------------

Description : (Not Specified)

SDP Id : 130:13 Type : Spoke

Split Horiz Grp : (Not Specified)

VC Type : CESoPSN VC Tag : 0

Admin Path MTU : 0 Oper Path MTU : 1556

Far End : 10.10.10.130 Delivery : LDP

Admin State : Up Oper State : Up

Acct. Pol : None Collect Stats : Disabled

Ingress Label : 131068 Egress Label : 131067

Ing mac Fltr : n/a Egr mac Fltr : n/a

Ing ip Fltr : n/a Egr ip Fltr : n/a

Admin ControlWord : Preferred Oper ControlWord : True

Admin BW(Kbps) : 0 Oper BW(Kbps) : 0

Last Status Change : 07/06/2012 14:38:49 Signaling : TLDP

Last Mgmt Change : 07/06/2012 14:34:23

Endpoint : N/A Precedence : 4

Class Fwding State : Down

Flags : None

Peer Pw Bits : None

Peer Fault Ip : None

Peer Vccv CV Bits : lspPing

Peer Vccv CC Bits : pwe3ControlWord mplsRouterAlertLabel

KeepAlive Information :

Admin State : Disabled Oper State : Disabled

Hello Time : 10 Hello Msg Len : 0

Max Drop Count : 3 Hold Down Time : 10

Statistics :

I. Fwd. Pkts. : 63158 I. Dro. Pkts. : 0

I. Fwd. Octs. : 5684220 I. Dro. Octs. : 0

E. Fwd. Pkts. : 63190 E. Fwd. Octets : 5687100

-------------------------------------------------------------------------------

CPIPE Service Destination Point specifics

-------------------------------------------------------------------------------

Local Bit-rate : 1 Peer Bit-rate : 1

Local Payload Size : 64 Peer Payload Size : 64

Local Sig Pkts : No Sig. Peer Sig Pkts : No Sig.

Local CAS Framing : No CAS Peer CAS Framing : No CAS

Local RTP Header : No Peer RTP Header : No

Local Differential : No Peer Differential : No

Local Timestamp : 0 Peer Timestamp : 0

-------------------------------------------------------------------------------

Number of SDPs : 1

-------------------------------------------------------------------------------

Service Access Points

-------------------------------------------------------------------------------

SAP 1/6/3.1

-------------------------------------------------------------------------------

Service Id : 13

SAP : 1/6/3.1 Encap : cem

Description : (Not Specified)

Admin State : Up Oper State : Up

Flags : None

Multi Svc Site : None

Last Status Change : 07/06/2012 15:48:36

Last Mgmt Change : 07/06/2012 14:34:03

Sub Type : regular

Split Horizon Group: (Not Specified)

Admin MTU : 1514 Oper MTU : 1514

Ingr IP Fltr-Id : n/a Egr IP Fltr-Id : n/a

Ingr Mac Fltr-Id : n/a Egr Mac Fltr-Id : n/a

Ingr IPv6 Fltr-Id : n/a Egr IPv6 Fltr-Id : n/a

tod-suite : None qinq-pbit-marking : n/a

Ing Agg Rate Limit : max Egr Agg Rate Limit: max

Endpoint : N/A

Acct. Pol : None Collect Stats : Disabled

-------------------------------------------------------------------------------

QOS

-------------------------------------------------------------------------------

Ingress qos-policy : 1 Egress qos-policy : 1

Shared Q plcy : n/a Multipoint shared : Disabled

I. Sched Pol : (Not Specified)

E. Sched Pol : (Not Specified)

-------------------------------------------------------------------------------

Sap Statistics

-------------------------------------------------------------------------------

Last Cleared Time : 07/06/2012 18:21:29

Packets Octets

Forwarding Engine Stats

Dropped : 0 0

Off. HiPrio : 60250 3856000

Off. LowPrio : n/a n/a

Queueing Stats(Ingress QoS Policy 1)

Dro. HiPrio : 0 0

Dro. LowPrio : n/a n/a

For. InProf : 60250 3856000

For. OutProf : 0 0

Queueing Stats(Egress QoS Policy 1)

Dro. InProf : n/a n/a

Dro. OutProf : n/a n/a

For. InProf : n/a n/a

For. OutProf : n/a n/a

-------------------------------------------------------------------------------

Sap per Queue stats

-------------------------------------------------------------------------------

Packets Octets

Ingress Queue 1 (Priority)

Off. HiPrio : 60250 3856000

Off. LoPrio : n/a n/a

Dro. HiPrio : 0 0

Dro. LoPrio : n/a n/a

For. InProf : 60250 3856000

For. OutProf : 0 0

Egress Queue 1

For. InProf : n/a n/a

For. OutProf : n/a n/a

Dro. InProf : n/a n/a

Dro. OutProf : n/a n/a

-------------------------------------------------------------------------------

CEM SAP Configuration Information

-------------------------------------------------------------------------------

Endpoint Type : NxDS0 Bit-rate : 1

Payload Size : 64 Jitter Buffer (ms) : 32

Jitter Buffer (packets): 4 Playout Threshold (packets): 3

Use RTP Header : No Differential : No

Timestamp Freq : 0 CAS Framing : No CAS

Effective PDVT : +/-16.0 ms

Cfg Alarm : stray malformed pktloss overrun underrun

Alarm Status :

-------------------------------------------------------------------------------

CEM SAP Statistics

-------------------------------------------------------------------------------

Packets Seconds Events

Egress Stats

Forwarded : 56306

Dropped : 0

Missing : 0

Reordered Forwarded : 0

Underrun : 0 0

Overrun : 0 0

Misordered Dropped : 0

Malformed Dropped : 0

LBit Dropped : 0

Error : 0

Severely Error : 0

Unavailable : 0

Failure Count : 0

Jitter Buffer Depth : 2

Ingress Stats

Forwarded : 56307

Dropped : 0

-------------------------------------------------------------------------------

Service Endpoints

-------------------------------------------------------------------------------

No Endpoints found.

===============================================================================

*A:SAR8-128#

A:SAR8-130# show service id 13 all

===============================================================================

Service Detailed Information

===============================================================================

Service Id : 13

Service Type : Cpipe VLL Type : CESoPSN

Description : G.703 VT Card Example

Customer Id : 1

Last Status Change: 07/06/2012 15:56:24

Last Mgmt Change : 07/06/2012 14:38:35

Admin State : Up Oper State : Up

MTU : 1514

Vc Switching : False

SAP Count : 1 SDP Bind Count : 1

-------------------------------------------------------------------------------

Service Destination Points(SDPs)

-------------------------------------------------------------------------------

Sdp Id 128:13 -(10.10.10.128)

-------------------------------------------------------------------------------

Description : (Not Specified)

SDP Id : 128:13 Type : Spoke

Split Horiz Grp : (Not Specified)

VC Type : CESoPSN VC Tag : 0

Admin Path MTU : 0 Oper Path MTU : 1556

Far End : 10.10.10.128 Delivery : LDP

Admin State : Up Oper State : Up

Acct. Pol : None Collect Stats : Disabled

Ingress Label : 131067 Egress Label : 131068

Ing mac Fltr : n/a Egr mac Fltr : n/a

Ing ip Fltr : n/a Egr ip Fltr : n/a

Admin ControlWord : Preferred Oper ControlWord : True

Admin BW(Kbps) : 0 Oper BW(Kbps) : 0

Last Status Change : 07/06/2012 14:38:35 Signaling : TLDP

Last Mgmt Change : 07/06/2012 14:38:32

Endpoint : N/A Precedence : 4

Class Fwding State : Down

Flags : None

Peer Pw Bits : None

Peer Fault Ip : None

Peer Vccv CV Bits : lspPing

Peer Vccv CC Bits : pwe3ControlWord mplsRouterAlertLabel

KeepAlive Information :

Admin State : Disabled Oper State : Disabled

Hello Time : 10 Hello Msg Len : 0

Max Drop Count : 3 Hold Down Time : 10

Statistics :

I. Fwd. Pkts. : 1734667 I. Dro. Pkts. : 0

I. Fwd. Octs. : 156120030 I. Dro. Octs. : 0

E. Fwd. Pkts. : 1734615 E. Fwd. Octets : 156115350

-------------------------------------------------------------------------------

CPIPE Service Destination Point specifics

-------------------------------------------------------------------------------

Local Bit-rate : 1 Peer Bit-rate : 1

Local Payload Size : 64 Peer Payload Size : 64

Local Sig Pkts : No Sig. Peer Sig Pkts : No Sig.

Local CAS Framing : No CAS Peer CAS Framing : No CAS

Local RTP Header : No Peer RTP Header : No

Local Differential : No Peer Differential : No

Local Timestamp : 0 Peer Timestamp : 0

-------------------------------------------------------------------------------

Number of SDPs : 1

-------------------------------------------------------------------------------

Service Access Points

-------------------------------------------------------------------------------

SAP 1/3/3.1

-------------------------------------------------------------------------------

Service Id : 13

SAP : 1/3/3.1 Encap : cem

Description : (Not Specified)

Admin State : Up Oper State : Up

Flags : None

Multi Svc Site : None

Last Status Change : 07/06/2012 15:56:24

Last Mgmt Change : 07/06/2012 14:38:16

Sub Type : regular

Split Horizon Group: (Not Specified)

Admin MTU : 1514 Oper MTU : 1514

Ingr IP Fltr-Id : n/a Egr IP Fltr-Id : n/a

Ingr Mac Fltr-Id : n/a Egr Mac Fltr-Id : n/a

Ingr IPv6 Fltr-Id : n/a Egr IPv6 Fltr-Id : n/a

tod-suite : None qinq-pbit-marking : n/a

Ing Agg Rate Limit : max Egr Agg Rate Limit: max

Endpoint : N/A

Acct. Pol : None Collect Stats : Disabled

-------------------------------------------------------------------------------

QOS

-------------------------------------------------------------------------------

Ingress qos-policy : 1 Egress qos-policy : 1

Shared Q plcy : n/a Multipoint shared : Disabled

I. Sched Pol : (Not Specified)

E. Sched Pol : (Not Specified)

-------------------------------------------------------------------------------

Sap Statistics

-------------------------------------------------------------------------------

Last Cleared Time : N/A

Packets Octets

Forwarding Engine Stats

Dropped : 0 0

Off. HiPrio : 1735702 111084928

Off. LowPrio : n/a n/a

Queueing Stats(Ingress QoS Policy 1)

Dro. HiPrio : 0 0

Dro. LowPrio : n/a n/a

For. InProf : 1735702 111084928

For. OutProf : 0 0

Queueing Stats(Egress QoS Policy 1)

Dro. InProf : n/a n/a

Dro. OutProf : n/a n/a

For. InProf : n/a n/a

For. OutProf : n/a n/a

-------------------------------------------------------------------------------

Sap per Queue stats

-------------------------------------------------------------------------------

Packets Octets

Ingress Queue 1 (Priority)

Off. HiPrio : 1735702 111084928

Off. LoPrio : n/a n/a

Dro. HiPrio : 0 0

Dro. LoPrio : n/a n/a

For. InProf : 1735702 111084928

For. OutProf : 0 0

Egress Queue 1

For. InProf : n/a n/a

For. OutProf : n/a n/a

Dro. InProf : n/a n/a

Dro. OutProf : n/a n/a

-------------------------------------------------------------------------------

CEM SAP Configuration Information

-------------------------------------------------------------------------------

Endpoint Type : NxDS0 Bit-rate : 1

Payload Size : 64 Jitter Buffer (ms) : 32

Jitter Buffer (packets): 4 Playout Threshold (packets): 3

Use RTP Header : No Differential : No

Timestamp Freq : 0 CAS Framing : No CAS

Effective PDVT : +/-16.0 ms

Cfg Alarm : stray malformed pktloss overrun underrun

Alarm Status :

-------------------------------------------------------------------------------

CEM SAP Statistics

-------------------------------------------------------------------------------

Packets Seconds Events

Egress Stats

Forwarded : 57083

Dropped : 0

Missing : 0

Reordered Forwarded : 0

Underrun : 0 0

Overrun : 0 0

Misordered Dropped : 0

Malformed Dropped : 0

LBit Dropped : 0

Error : 0

Severely Error : 0

Unavailable : 0

Failure Count : 0

Jitter Buffer Depth : 2

Ingress Stats

Forwarded : 57082

Dropped : 0

-------------------------------------------------------------------------------

Service Endpoints

-------------------------------------------------------------------------------

No Endpoints found.

===============================================================================

A:SAR8-130#

2. Verify the channel group statistics (only the show output for port 1/6/3.codir on SAR8-128 is displayed below):

A:SAR8-128# show port 1/6/3.codir

===============================================================================

TDM Data Interface

===============================================================================

Description : CODIR

Interface : 1/6/3.codir

Type : codir

Admin Status : up Oper Status : up

Physical Link : yes Clock Source : node-timed

Timing 8khz : Disabled

Last State Change : 07/06/2012 15:48:36 Channel IfIndex : 583106563

Loopback : none

Cfg Alarm : ais los

Alarm Status :

===============================================================================

Traffic Statistics

===============================================================================

Input Output

-------------------------------------------------------------------------------

Octets 8262144 8262144

Packets 129096 129096

Errors 0 0

===============================================================================

Port Statistics

===============================================================================

Input Output

-------------------------------------------------------------------------------

Packets 129096 129096

Discards 0 0

Unknown Proto Discards 0

===============================================================================
